Fiber Optic 1X8 Mini PLC splitter SC APC Connector 0.9mm, 1M

Name: Fiber Optic 1X8 Mini PLC splitter SC APC Connector 09mm 1M
Brand: DOWELL
Price: 1 USD

Wholesale Fiber Optic 1X8 Mini PLC splitter SC APC Connector 0.9mm, 1M from china suppliers

Model Number : DW-M1X8

Place of Origin : Zhejiang, China

Brand Name : DOWELL

Supply Ability : 1000 PCS Per 7 Days

MOQ : 500 pieces

Payment Terms : T/T, Western Union, Paypal

Delivery Time : 7-15 Days

Parameter : 1X2, 1x4, 1x8, 1x16, 1x32, 1x64

Wavelength : 1260 ～ 1650nm

Operating temp : -40~85℃

Storage temp : Storage temp

Humidity : ≤95%（+40℃）

Connector : SC, FC, LC

Contact Now

Fiber Optic 1X8 Mini PLC splitter SC APC Connector 0.9mm, 1M

A mini-type fiber optic PLC (Planar Lightwave Circuit) splitter is a compact, high-performance passive optical device used to split an incoming optical signal into multiple output signals with minimal loss. It is widely used in FTTH (Fiber to the Home), PON (Passive Optical Network), and other fiber optic communication systems.

Specification:

1×N(N≥2)PLC Splitter(with connector)optical parameter

Parameter		1X2	1x4	1x8	1x16	1x32	1x64
Wavelength(nm)		1260 ～ 1650
IL(dB)		≤4.1	≤7.4	≤10.5	≤13.8	≤17.1	≤20.4
Uniformity(dB)		≤0.6	≤0.7	≤0.8	≤1.0	≤1.5	≤2.0
RL(dB)		≥50(PC),≥55(APC)
PDL(dB)		≤0.15	≤0.2	≤0.2	≤0.3	≤0.3	≤0.3
Directivity(dB)		≥55	≥55	≥55	≥55	≥55	≥55
Environment	Operating temp(℃)	-40~85℃
	Storage temp(℃)	-40~85℃
	Humidity	≤95%(+40℃)
	Atmospheric pressure	62~106kPa
Fiber		SM G657A or customized
Connector		SC, FC, LC
Pigtail(mm)		1000, 1500, 2000 or customized

Remark :(1) Test in room temperature and include connector.

(2) R ≥55dB without connector

Features:

1.1 Qualified with CE certificate and ROHS certificate.

1.2 Comply with GR-1209-CORE, GR-1221-CORE, YD/T 2000.1-2014 and IEC criterion.

Application:

2.1 FTTH (Fiber to the Home) networks
2.2 PON (Passive Optical Network) systems (GPON, EPON, XGSPON)
2.3 CATV & telecom distribution
2.4 Data centers & enterprise networks
