Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
A Fiber Optic Multimode Patch Cord (also called a multimode fiber jumper) is a short, flexible cable with connectors on both ends, used to connect optical devices in high-speed data communication networks. It is designed for short-distance, high-bandwidth applications, commonly found in data centers, LANs (Local Area Networks), and enterprise networks.
Specification:
| Parameter |
Unit |
Mode |
PC |
UPC |
APC |
| Type |
| Insertion Loss |
dB |
SM |
<0.3 |
<0.3 |
<0.3 |
| |
|
MM |
<0.3 |
<0.3 |
|
| Return Loss |
dB |
SM |
>50 |
>50 |
>60 |
| |
|
MM |
>35 |
>35 |
|
| Repeatability |
dB |
Additional loss<0.1db, return loss< 5 dB |
| Interchangeability |
dB |
Additional loss<0.1db, return loss< 5 dB |
| Connection Times |
times |
>1000 |
| Operating Temperature |
°C |
-40 C- +75 C |
| Storage Temperature |
°C |
-40 C- +85 C |
Features:
1.1 Fiber Type – OM1, OM2, OM3, OM4, or OM5 (supporting different bandwidths and distances):
OM1 (62.5µm) – Up to 275m @ 1Gbps
OM2 (50µm) – Up to 550m @ 1Gbps
OM3 (50µm, laser-optimized) – Up to 300m @ 10Gbps
OM4 (50µm, enhanced bandwidth) – Up to 400m @ 10Gbps
OM5 (50µm, wideband multimode) – Supports SWDM for 40G/100G
1.2 Core Diameter – Typically 50µm or 62.5µm, allowing multiple light modes to propagate.
1.3 Jacket Types –
PVC (general indoor use)
LSZH (Low Smoke Zero Halogen) – For fire safety in data centers
Armored – Extra protection in harsh environments
Application:
2.1 Telecommunication Network
2.2 Fiber Broad Band Network
2.3 CATV system
2.4 LAN and WAN system
2.5 FTTP
